HDPE Geomembrane

Product Description

Industry-specific attributes


  Warranty

  years

  After-sale Service

  Online technical support

  Project Solution Capability

  Others

  Application

  Outdoor, pond, landfill, mine etc

  Design Style

  Industrial


Other attributes


  Place of Ongin

  China

  Type

  Geomembrane

  Brand Name

  Dingrun

  Product Name

  Rough geomembran

  Material

  HDPE LDPE LLDPE

  Color

  Black white blue or as required

  Keyword

  Geomembranes

  Length

  50-200m/roll or as requirement

  Width

  2m-8m

  Thicknes

  0 . 5mm-2.5mm


PRODUCT PARAMENTERS/geomembrane data


Item

Index

The thickness(mm)

0.7511.251.522.53

The density(g/cm2)

≧0.94

Coarse height(mm)

≧0.25

Tensile yield strength(The horizontal and vertical)N/mm

≧11

≧15

≧18

≧22

≧29

≧37

≧44

Tensile fracture strength(The horizontal and vertical)N/mm

≧8

≧10

≧13

≧16

≧21

≧26

≧32

Yield elongation(The horizontal and vertical)%

≧12

Elongation at break (longitudinal and transverse)%

≧100

Right-angle tearing load (longitudinal and transverse)N

≧93

≧125

≧160

≧190

≧250

≧315

≧375

Puncture resistance N

≧200

≧270

≧335

≧400

≧535

≧670

≧800

Stress cracking under tensile load (dead-load tensile method with notch)h

≧300

Carbon black content%

2.0~3.0

Oxidation induction time(OIT)

Induction time of oxidation at atmospheric pressure100

Induction time of high pressure oxidation≧400

85℃ thermal aging (OIT retention rate at atmospheric pressure after 90 days)

≧55


Uv resistance (OIT retention rate after 1600h UV irradiation)

≧50


Features

1) Good physical and mechanic performance

2) High tearing resistance, strong deformation adaptability

3) Puncture-resisting, aging resisting, ultra-violet radiation, oil and salt, and corrosion resistance

4) Good adaptability to high and low temperature, non-toxicity, long service life

5) Good waterproof, drainage, anti-seepage and damp proof effects

6) Complete width and thickness specifications, low cost and easy installation.


Aquaculture Industry

1Aquaculture

For example , industrialized aqua -culture ponds , fish ponds , shrimppons lining , sea cucumber circleprotection , etc .

2Water Conservancy

For example , seepage preventionleakage stoppage , and reinforcement of rivers . lakes , reservoirs and slope

protection , etc

3Municipal Engineering

For example , tunnel , subway , underground works of buildings and roof cisterns , impervious roof garden , lining

of sewage pipes,ete

4Petrifaction

For example , anti seepage of oil storage tanks in chemicalplants, refineries and gas stations , lining of chemical

reaction tank and sedimentation tank , secondary lining , etc.




HDPE Geomembrane Pond Liner WaterproofImpermeable Smooth Textur 0 . 5mm 0 . 75mm 1 . 0mm 1 . 5mm

2 . 0mm White Black Smooth TeturedHDPE Waterproof Geomembrane for Dam Liner fish pond water reservoir.


HDPE EVA EPDM PVC Waterproof Geomembrane Plastic Pond Liner for Fish Pond Landfill Dam Mining Lagoon

Factory direct sales price discount , high-quality EVA tunnel geotextile film.


Composite geomembrane is compounded with geotextiles and geomembrane impermeable material , it is mainly

used for seepage control HDPE Composite geomembrane and nonwoven geotextile for landfill.











FAQ

Q1. Can you do OEM?

A1. Yes.of course.We can produce the products as per your request.

If you can offer samples to us,it will be more convenient.



Q2. If I want to order a small quantity goods,can you do it?

A2. If the product you need we have stock available,that would be great,you can choose the instock goods.

but if not, don’t worry, we can take your order with our other clients’ order to be produced together.But it needs to wait some time .



Q3: Can you arrange the shipment for us?

A3: Yes, Our freight forwarders are through the company tender, signed long-term agreement, Price Service is the best. we have designated sea-freight and railway freight Forwarders with decades of experiences and we can get the best price with earliest vessel and professional services.



Q4. How will you follow my order?

A4. When the goods are started to produce,we will take photos for the goods and send it to you.

If you find any production deficiencies,please contact us to correct it.

We will keep in touch with you in the whole production by e-mail or instant messaging, like Skype/Viber/WhatsApp, you can get the

latest news about your order.

After the goods are finish,we will take photos for the goods and packing to you before shipping.



Q5. What is your exporting countries?

A5. We have good sales performance and win good international reputation in more than 30 Countries and

regions,such as Japan, America, Australia,Russia, Canada,Middle East and so on.

Especially in the Middle East and Australia market.
