Product Description
 Voltage:  220V/110V
 Frequency:  50/60Hz
 Power:  1800W
 Welding Speed:  0.5-5 m/min
 The temperature of Heating up:  0~450°C
 The thickness of welding material:  1.0mm~3.0mm
 Welding width:  15mm×2
 Interior Cavity:  15mm
 Seam strength:  ≥85% base material
 Overlap width:  12cm
 Weight:  13kg
 Insulation class:  class II


 SWT-NS900 Parameter Settings  Reference Speed  Reference Temperature  Reference Pressure Value (When upper and lower pressure roller in 0 pressure state)
 HDPE 1.0mm  3.0-4.5  380-430  Counterclockwise adjustment is recommended at 4
 HDPE 1.5mm  2.5-4.0  380-430  Counterclockwise adjustment is recommended at 3
 HDPE 2.0mm  2.0-3.5  380-430  Counterclockwise adjustment is recommended at 2
 HDPE 3.0mm  1.5-2.5  380-430  Clockwise adjustment is recommended to be 1-2


SWT-NS900 Hot Wedge Welding Machine

SWT-NS900 HDPE geomembrane hot air wedge welding machine, handheld plastic extruder welding machine

Introduction:

SWT-NS900 adopts advanced hot air heating system. It is small in size, light in weight, and fast in speed, and can improve welding quality even in corrosive materials and harsh working environments. This machine is designed specifically for waterproofing projects such as tunnels, subways, water conservancy, aquaculture, biogas plants, landfills, chemical mines, sewage treatment, roof construction, etc.

Tips:

1. This machine adopts steel pressure roller welding, suitable for hot air welding.

2. We have multiple models of welding machines. If you have any customization needs, you can contact us directly. We have a professional technical team.


Application of Hot Wedge Welding Machine:
Geomembrane Welding Machine can weld geo-membrane of various thickness and are applicable for welding of all thermal-fused material such as PE,PVDF,LDPE, PVC, HDPE, EVA, PP and HDPE,EVA,PP.
Geomembrane Welding equipments are designed for water conservancy,aquaculture,landfills,chemical mining,sewage treatment,roof construction, and other waterproofing projects.

1























FAQ

Q1. Can you do OEM?

A1. Yes.of course.We can produce the products as per your request.

If you can offer samples to us,it will be more convenient.



Q2. If I want to order a small quantity goods,can you do it?

A2. If the product you need we have stock available,that would be great,you can choose the instock goods.

but if not, don’t worry, we can take your order with our other clients’ order to be produced together.But it needs to wait some time .



Q3: Can you arrange the shipment for us?

A3: Yes, Our freight forwarders are through the company tender, signed long-term agreement, Price Service is the best. we have designated sea-freight and railway freight Forwarders with decades of experiences and we can get the best price with earliest vessel and professional services.



Q4. How will you follow my order?

A4. When the goods are started to produce,we will take photos for the goods and send it to you.

If you find any production deficiencies,please contact us to correct it.

We will keep in touch with you in the whole production by e-mail or instant messaging, like Skype/Viber/WhatsApp, you can get the

latest news about your order.

After the goods are finish,we will take photos for the goods and packing to you before shipping.



Q5. What is your exporting countries?

A5. We have good sales performance and win good international reputation in more than 30 Countries and

regions,such as Japan, America, Australia,Russia, Canada,Middle East and so on.

Especially in the Middle East and Australia market.
